Brief introduction This series of air control slow closing check valve is mainly installed in outlet of water pump or fan in gas and liquid pipeline systems. Through the opening and closing of the preset program, open the whole stroke of low flow resistance, two stages of closed, effectively eliminate the pipeline water hammer and…
Driving Mode Electric, Pneumatic Nominal Size DN40~600mm Pressure Rating PN10 PN16 PN25 CL150~300LB Media Gas, Water, Oil Accessories Limit switch, Positioner, Solenoid valve, Air filter regulator, Handwheel Connection Standard ASME B 16.5 Brief introduction Triple Off Set Pneumatic Butterfly Valve With Positioner 1. The valve adopts three eccentric sealing structure. The valve seat and butterfly…
Size Range 2″-40″ Pressure PN10, PN16, Class150 Body Materials Stainless Steel Seat Materials Stainless steel Disc Materials WCB, CF8,CF8M Stem Materials SS304, SS316 End Connection Wafer Operate Worm gear Brief introduction Triple offset Metal seated Butterfly Valve is light weight, easy to adjust flow, widely used in hydro power station, building industry, petroleum, chemical, steel,paper…
Brief introduction Hydraulic station is composed of motor oil pump, manifold or valve combination, fuel tank, electrical control box combination. The function of each component is as follows: Motor oil pump – the motor and oil pump, which is the power source of the hydraulic station, the mechanical energy into hydraulic oil power. The manifold…
Brief introduction Hydraulic pump unit consisting of following main components: All associated valves such as distributing, proportional, control ,emergency shutdown, check valves including other types, piping, fitting etc. Oil filtration unit with changeover facility along with clogging indication Oil sump tank Motor driven main and standby oil pumps mounted on the sump tank Oil pressure…
DN 300mm~2400mm PN 0.25~4MPa Pressure test seat 1.1*PN shell 1.5*PN Medium water Working pressure 0.8*PN Flow rate 1.0~4.5m/s Brief introductionWorking principle The emergency trip valve mainly composed by :main valve( including counterweight device), velocity sensor part (velocity sensor), tube parts, hydraulic system (including the buffer cylinder, oil and oil passage). The results are shown in…
Size: DN200-DN2000 Design pressures:25 bar to 100 bar Soft or metallic seals Hydraulically operated seal ring Double eccentric with maintenance seal Limit Switch for close and open position Brief introductionMain Part MaterialProject References High pressure hydraulic Power Station Spherical Valve (Also Named Hydraulic Power Station Ball Valve) is one of advanced control equipment which installed…
Size: 2” up to 48” Pressure: PN6-PN25 Materials: Ductile Iron, WCB, CF8M, Aluminum Bronze, Aluminum Wafer and Lug Type Operation: Electric actuator, pneumatic, hydraulic actuator etc. Brief introductionProject References Easy replacement without using tools in the event of accidental breakage. The rubber seat protects the valve body from the fluid and with the disc are…
DN 80mm~1200mm PN ASME Class 150, 300 and 600 Pressure test seat 1.1*PN shell 1.5*PN Medium temperature ≤425℃ medium Steam, gas etc. Body Material Carbon Steel, Stainless Steel & Other Materials Connection Wafer, Lug, Flange, butt weld Brief introduction Triple offset butterfly valves are designed in accordance with API 609 with features of bi-directional, lightweight…
DN （Size Range） 80mm~1200mm PN （Pressure Range） ASME Class 150 – 600 Pressure test seat 1.1*PN shell 1.5*PN Medium temperature ≤425℃ medium Steam, gas etc. Working pressure 0.8*PN Standard Connection Flange， lug， butt weld， Wafer Brief introduction Triple offset Metal seated Butterfly Valve is light weight, easy to adjust flow, widely used in hydro power…
